广西武宣土洞发育水动力条件评价

姜伏伟

姜伏伟. 广西武宣土洞发育水动力条件评价[J]. 水文地质工程地质, 2017, 44(2): 90-95.
引用本文: 姜伏伟. 广西武宣土洞发育水动力条件评价[J]. 水文地质工程地质, 2017, 44(2): 90-95.
JIANGFuwei. Assessment on the hydraulic condition of forming soil-caves collapse in Wuxuan, Guangxi, China[J]. Hydrogeology & Engineering Geology, 2017, 44(2): 90-95.
Citation: JIANGFuwei. Assessment on the hydraulic condition of forming soil-caves collapse in Wuxuan, Guangxi, China[J]. Hydrogeology & Engineering Geology, 2017, 44(2): 90-95.

广西武宣土洞发育水动力条件评价

基金项目:

贵州省教育厅青年科技人才成长项目(黔教合KY字[2016]226)

Assessment on the hydraulic condition of forming soil-caves collapse in Wuxuan, Guangxi, China

  • 摘要: 本文分析了武宣土洞发育的地质背景、水动力诱发土洞的过程,在理想条件下,建立了土体渗透破坏形成土洞的管道流机理模型,根据管道流理论,分析得出土洞发育水动力条件表达式。通过自行设计的管道流测试仪装置,进行管道流模拟试验,计算得出研究区土洞发育的临界切应力为21.20 Pa。运用电子扫描电镜技术,测试研究区孔隙等效直径为31.6 nm,计算得出研究区土洞发育的临界水流为0.530 cm/min。对比临界水流和现场监测的实际地下水流,评价土洞发育的可能性。结果表明,目前情况下,地下水流未达到临界值,不具备引起黏土流失形成土洞的水动力条件。
    Abstract: This paper analyzes the geological background and the process induced by the hydrodynamics of developing soil-caves in Wuxuan, a city in Guangxi Provence, china. Under ideal conditions, the mechanism model of the seepage failure of soil to forming soil-caves is the pipe flow. From the theory of the pipe flow, it establishes the expression of the hydrodynamics causing the soil-caves. Next, through the experiment designed to simulate the pipe flow, it obtains the critical shear stress 21.20 Pa to lead to soil-caves in the study area. The equivalent diameter of soil pores is 31.6 nm tested by the electron scanning microscopy. With the known parameters, it calculates the critical velocity of ground water 0.530 cm/min. Comparing the monitoring data of the ground water in the field with the critical hydraulic values, the study assesses the probability of the soil-caves collapse. The result shows that the current hydraulic condition doesn’t have enough the dynamic to form the soil-caves collapse in Wuxuan.
  • [1] [1]康彦仁,项式均.中国南方岩溶塌陷[M].南宁:广西科学出版社,1990:23-24.

    [KANG Y R, XIANG S J. Karst collapse in south China[M]. Nanning: Guangxi Science Press,1990:23-24.(in Chinese)]

    [2] [2]雷谦荣.关于地下侵蚀土洞的形成机理与影响因素[J].地下空间,1987(2):62-65.

    [LEI Q R. On the formation mechanism and influencing factors of underground erosion soil cave[J].Underground Space, 1987(2):62-65.(in Chinese)]

    [3] [3]谭鉴益,覃新丹,蔡峰.岩溶塌陷形成机理探讨[J].广西地质,1992(2):77-82.

    [TAN J Y, QIN X D, CAI F. A discussion on the mechanism of karst collapse[J]. Geology of Guangxi, 1992(2):77-82. (in Chinese)]

    [4] [4]袁莉明.岩溶地区土洞的发育机制及治理[J].土工基础, 2002, 16(1): 5-6.

    [YUAN L M. The development mechanism and remedy of earth caves in karst area[J]. Soil Engineering and Foundation, 2002, 16(1):5-6. (in Chinese)]

    [5] [5]陈荣波,郑水清.岩溶土洞的工程特性与鉴别[J].广东土木与建筑,2004(2):21-24.

    [CHEN R B, ZHENG S Q. Study on the engineering properties and identification of soil-cave[J]. Guangdong Architecture Civil Engineering, 2004(2): 21-24. (in Chinese)]

    [6] [6]覃羡安,王昆,宋平,等.昆明新机场土洞形成机理及发育规律研究[J].岩土工程界,2009(3):31-33.

    [QIN X A, WANG K, SONG P, et al. Research on the formation mechanism and developing regularity of the soil-cave in the international airport in Kunming[J]. Geotechnical Engineering World,2009(3):31-33. (in Chinese)]

    [7] [7]蒋小珍,雷明堂,管振德.单层土体结构岩溶土洞的形成机理[J].中国岩溶,2012,31(4):426-432.

    [JIANG X Z, LEI M T, GUAN Z D. Formation mechanism of karst soil-void in single-layer soil structure condition[J]. Carsologica Sinica,2012,31(4):426-432. (in Chinese)]

    [8] [8]李颜贵,刘子龙,于孝民,等.唐山黄庄岩溶塌陷形成条件和机理分析[J].中国岩溶,2014,33(3):299-307.

    [LI Y G, LIU Z L, YU X M, et al. Formation conditions and mechanisms of karst subsidence:A case study of Huangzhuang village in Tangshan[J]. Carsologica Sinica, 2014,33(3):299-307. (in Chinese)]

    [9] [9]张海坦,李庆华,邓书金.歌乐山岩溶地面塌陷发育特征[J].中国岩溶,2015,34(1):58-63.

    [ZHANG H T, LI Q H, DENG S J. Development characters of karst collapse in the Gele mountain area[J]. Carsologica Sinica, 2015,34(1):58-63. (in Chinese)]

    [10] [10]陈裕昌.岩溶地面塌陷模型设计与试验[J].铁道工程学报,1989(3):93-100.

    [CHEN Y C. Design and experimental model of karst collapse[J]. Journal of Railway Engineering Society, 1989(3): 93-100. (in Chinese)]

    [11] [11]雷明堂,蒋小珍,李瑜.岩溶塌陷模型试验——以武昌为例[J].地质灾害与环境保护,1993(2):39-44.

    [LEI M T, JIANG X Z, LI Y. Model experiment of karst collapse: as a case in Wuchang[J]. Journal of Geological Hazards and Environment Preservation, 1993(2):39-44. (in Chinese)]

    [12] [12]雷明堂,蒋小珍,李瑜.唐山市岩溶塌陷模型试验研究[J].中国地质灾害与防治学报,1997(增刊1):187-194.

    [LEI M T, JIANG X Z, LI Y. Model experiment of karst collapse in Tangshan[J]. The Chinese Journal of Geological Hazard and Control, 1997(Sup 1):187-194. (in Chinese)]

    [13] [13]蒋小珍.岩溶塌陷发育条件的试验研究[J].中国地质灾害与防治学报,1998(增刊1):191-195.

    [JIANG X Z. The Experimental Study of Karst Collapse Condition[J]. The Chinese Journal of Geological Hazard and Control, 1998(Sup 1):191-195. (in Chinese)]

    [14] [14]陈学军,周明芳,陈富坚,等.岩溶地区破坏性抽水致塌试验研究——以广西桂林西城区为例[J].地质科技情报, 2002(1):79-82.

    [CHEN X J, ZHOU M F, CHEN F J, et al. Destructive pumping test to study the characteristics of karst collapse in limestone region: a case study in the western urban area of Guilin city[J]. Geological Science and Technology Information, 2002(1): 79-82. (in Chinese)]

    [15] [15]万志清,秦四清,李志刚,等.土洞形成的机理及起始条件[J].岩石力学与工程学报,2003,22(8):1377-1382.

    [WAN Z Q,QIN S Q,LI Z G,et al. Formation mechanism and initial condition of soil cavity[J]. Chinese Journal of Rock Mechanics and Engineering, 2003,22(8): 1377-1382. (in Chinese)]

    [16] [16]刘之葵,梁金城,周健红.岩溶区土洞发育机制的分析[J].工程地质学报,2004,12(1):45-49.

    [LIU Z K, LIANG J C, ZHOU J H. Analysis of formation mechanism of soil caves in karstic area[J]. Journal of Engineering Geology, 2004,12(1): 45-49. (in Chinese)]

    [17] [17]欧阳振华,蔡美峰,李长洪.地表塌陷中隐伏土洞的形成与扩展机理研究[J].金属矿山,2006 (6): 16-18.

    [OUYANG Z H, CAI M F, LI C H. Study on formation and expansion mechanism of hidden soil cavity in ground collapse[J]. Metal Mine, 2006(6):16-18. (in Chinese)]

    [18]

    [18]Waltham T, Bell F, Culshaw. Sinkholes and subsidence[M]. Karst and cavernous rocks in engineering and construction. Springer, Chichester, 2005.

    [19]

    [19]White W B. Geomorphology and Hydrology of Karst Terrains[M]. Oxford University Press: New York, 1988: 464.

    [20]

    [20]Ford D C, Williams P F. Karst Geomorphology and Hydrology[M]. Unwin Hyman: London, 1989:601.

    [21]

    [21]Beck B F. Environmental and engineering effects of sinkholes: The processes behind the problems[J]. Environ Geol Water Sci, 1988, 12:71-78.

    [22]

    [22]Sowers G F. Building on sinkholes[M]. ASCE, New York, 1996:202.

    [23] [23]姜伏伟,雷明堂,管正德,等.土洞发育水动力判据及应用研究[J].工程地质学报,2014,22(增刊1):77-82.

    [JIANG F W, LEI M T, GUAN Z D, et al. Study on the critical hydraulic condition of forming soil-caves in karst area[J]. Journal of Engineering Geology,2014,22(Sup 1):77-82. (in Chinese)]
