小乔木根系根土间作用力的室外拉拔试验研究

王桂尧; 胡圣辉; 张永杰; 陈曙; 沙琳川; 杨闻达

小乔木根系根土间作用力的室外拉拔试验研究

基金项目:

国家自然科学基金项目资助(51178063，51578082)；湖南省交通科技计划项目资助(201514)

计量
- 文章访问数: 949
- HTML全文浏览量: 15
- PDF下载量: 775
出版历程
- 收稿日期: 2017-06-03
- 修回日期: 2017-07-13

An outdoor drawing test study of the root soil interaction force for a small tree root system

WANGGuiyao,

摘要

摘要: 小乔木根系在边坡生态防护中具有相当高的比例，研究土壤贫瘠小乔木根系的护坡机理及影响因素，对进一步提高或改进边坡生态防护技术具有理论和实际意义。在综合国内外相关研究成果的基础上，通过室外拉拔试验研究了红黏土边坡湿地松根系在大气降雨、含水率、根系几何参数等变动情况下根系对坡面土体加固能力的影响。试验结果表明强降雨条件下，表层土体的含水率大于深层土体的含水率，含根土体含水率大于素土含水率，表明小乔木根系有助于坡面土的雨水入渗；最大拉拔力随含水率的增加表现为单调递减或在最优含水率附近最大的先增大后减小的趋势，两者间为二次函数的关系；最大拉拔力随根系体积的增加总体表现单调递增，但在含水率为22%和24%时，最大拉拔力随根系体积的增加先减小后增大；植物根系在不同体积或含水率下，拉拔力-位移曲线波动较大。
- 小乔木根系 /
- 根土间作用力 /
- 拉拔试验 /
- 雨水影响
Abstract: Small trees have a very high proportion in slope ecological protection. A study of the mechanism of slope protection and influence factors of a small tree root system are of important theoretical and practical significance for further improvement of the slope protection technology. On the basis of domestic and foreign research achievements, the influence of moisture content and root geometric parameters on the strengthening ability of slope soil is examined by the outdoor drawing experiment in red clay ground with the pinus elliottii root system. The results show that moisture content of the surface soil is greater than that in the deep soil after heavy rainfall condition and moisture content of the root soil is less than that in the nature soil. It is found that the small tree root system helps the water to infiltrate in the slope. The maximum drawing force increases first and then decreases with the increasing moisture content as the trend of the quadratic function; the maximum drawing force increases monotonically with the increasing root volume over all the performance, but when moisture content is 22% and 24%，the maximum drawing force decreases first and then increases with the increasing root volume. The pullout force displacement curve fluctuates greatly under different volume or moisture content of the plant root.
- small tree root system /
- root soil interaction force /
- drawing test /
- rain affect

HTML全文

参考文献(13)

[1]	［1］夏振尧,管世烽,牛鹏辉. 麦冬和多花木蓝根系抗拉拔特性试验研究［J］. 水土保持通报,2015,35(6):110-113. ［XIA Z Y, GUAN S F, NIU P H. Experimental study on pull-out resistive properties of Ophiopogon Japonicus and lndigofera Amblyantha Roots［J］.Bulletin of Soil and Water Conservation,2015,35(6):110-113 (in Chinese)］
[2]	［2］李国荣, 胡夏嵩, 毛小青. 寒旱环境黄土区小乔木根系护坡力学效应研究［J］. 水文地质工程地质,2008,35(1)：94-97. ［LI G R, HU X S, MAO X Q. A study of the mechanical effects of shrub roots for slope protection in frigid and arid-semiarid loess area［J］. Hydrogeology ＆ Engineering Geology,2008,35(1)：94-97 (in Chinese)］
[3]	［3］管世烽, 夏振尧, 张伦. 水平荷载作用下多花木蓝根系拉拔试验研究［J］. 长江科学院院报,2016,33(6):24-28. ［GUAN S F, XIA ZY, ZHANG L. Pull-out test of indigofera amblyantha craib root under horizontal load［J］. Journal of Yangtze River Scientific Research Institute,2016,33(6):24-28 (in Chinese)］
[4]	［4］李绍才，孙海龙，杨志荣,等.护坡植物根系与岩体相互作用的力学特性［J］. 岩石力学与工程学报，2006，25(10)：2051-2057. ［LI S C, SUN H L, YANG Z R, et al. Mechanical characteristics of interaction between root system of plants and rock for rock slope protection［J］. Chinese Journal of Rock Mechanics and Engineering, 2006，25(10)：2051-2057 (in Chinese)］
[5]	［5］胡夏嵩, 陈桂琛, 周国英,等. 青藏铁路沱沱河段路基边坡植物护坡根系力学强度试验研究［J］. 水文地质工程地质,2012,39(1):107-113. ［HU X S, CHEN G C, ZHOU G Y, et al. A study of the mechanic strength of vegetation roots for roadbed slope protection in the Tuotuohe river region along the Qinghai-Tibet railway［J］.Hydrogeology ＆ Engineering Geology,2012,39(1):107-113 (in Chinese)］
[6]	［6］张兴玲，胡夏嵩，李国荣,等.寒旱环境草本植物根系护坡的时间尺度效应［J］.水文地质工程地质，2009，36(4)：117-120. ［ZHANG X L, HU X S, LI G R, et al. Time scale effect of herb roots on slope protection in a cold, arid and semi-arid environment［J］. Hydrogeology ＆ Engineering Geology, 2009，36(4)：117-120 (in Chinese)］
[7]	［7］朱清科, 陈丽华, 张东升. 贡嘎山森林生态系统根系固土力学机制研究［J］. 北京林业大学学报,2002,24(4):64-67. ［ZHU Q K, CHEN L H, ZHANG D S. Mechanisms of soil-reinforcement by roots in forest ecological systems in Gongga Mountain［J］. Journal of Beijing Forestry University,2002,24(4):64-67 (in Chinese)］
[8]	［8］杨永红,刘淑珍,王成华,等. 浅层滑坡生物治理中的乔木根系抗拉实验研究［J］. 水土保持研究,2007,14(1):138-140. ［YANG Y H, LIU S Z, WANG C H, et al. A study of tensile strength tests of arborous species root system in forest engineering technique of shallow landslide［J］. Research of Soil and Water Conservation, 2007,14(1):138-140 (in Chinese)］
[9]	［9］陈丽华, 余新晓, 张东升,等. 整株林木垂向抗拉试验研究［J］. 资源科学,2004,26(7): 39-43. ［CHEN L H, YU X X, ZHANG D S, et al. Experimental study on vertically tensile strength of whole tree［J］. Resources Science, 2004,26(7):39-43 (in Chinese)］
[10]	［10］朱海丽, 胡夏嵩, 毛小青. 青藏高原黄土区护坡小乔木植物根系力学特性研究［J］. 岩石力学与工程学报,2008,27(增刊2):3445-3452. ［ZHU H L, HU X S, MAO X Q. Study on mechanical characteristics of shrub roots for slope protection in loess area of Tibetan Plateau［J］. Chinese Journal of Rock Mechanics and Engineering,2008,27(Sup 2):3445-3452 (in Chinese)］
[11]	［11］罗春燕,吴楚,芦光新,等. 三江源区植物根-土复合体的最大拉拔力特征及影响因素分析［J］. 水土保持研究,2014,21(5):260-266. ［LUO C Y, WU C, LU G X, et al. Tensile resistance characteristics of root-soil composite system and influence factor analysis in Sanjiangyuan Regions of Qinghai-Tibet Plateau［J］. Research of Soil and Water Conservation, 2014,21(5):260-266 (in Chinese)］
[12]	［12］Operstein V, Frydman S. The influence of vegetation on soil strength［J］.Ground Improvement,2000(4):81-89.
[13]	［13］Gray D H. Influence of vegetation on the stability of slopes［J］.Vegetation and slopes,1995:3-25.
