滹沱河冲洪积扇地下水硝酸盐的污染特征及污染源解析
Characteristics and source apportionment of groundwater nitrate contamination in the Hutuo River alluvial-pluvial fan regions
-
摘要: 为研究滹沱河冲洪积扇地区地下水硝酸盐污染机制，对滹沱河冲洪积扇地区地下水和地表水进行了采样监测，运用环境健康风险评价模型对研究区硝酸盐进行评价，采用水化学和多元统计方法研究了滹沱河冲洪积扇地区地下水硝酸盐污染问题。结果表明：研究区地表水NO-3污染较轻，NO-3均值为19.54 mg/L，所有水样均未超出我国地表水环境质量标准（45 mg/L）；但是，地下水已经受到了NO-3的严重污染，NO-3均值为75.84 mg/L，且有30.43%水样超出我国地下水质量标准（88. 6 mg/L）。研究区3个水文地质单元地下水硝酸盐的平均个人年健康风险分别为4.94×10-8、1.99×10-8和2.61×10-9，低于国际辐射防护委员会（ICRP）推荐的最大可接受风险水平（5.0×10-5/a），因此，认为不会对人群构成严重危害。水文地质单元和地下水埋深对硝酸盐污染有显著影响，但是，土地利用类型对硝酸盐浓度的影响不显著。滹沱河冲洪积扇地区地下水硝酸盐的主要污染来源是生活污水和化肥。此外，强烈开采地下水也是该地区NO-3污染的诱因。Abstract: Based on investigation of groundwater and surface water of the Hutuo River alluvial-pluvial fan in October, 2015, the pollution mechanism of nitrate in the region were identified by using the water chemical and multivariate statistical technology. The results show that the nitrate contamination is lighter for surface water and the mean concentration of nitrate is 19.54 mg/L, and all the samples are not over the environmental quality standard for surface water in China (GB-3838—2002). For groundwater, however, the mean concentration of nitrate is 75.84 mg/L and 30.43% of the samples are over the quality standard in China (88.6 mg/L), indicating that the groundwater has suffered serious nitrate pollution. The personal annual risk caused by nitrate in three hydrogeological units of the Hutuo River alluvial-pluvial fan regions are 4.94×10-8, 1.99×10-8 and 2.61×10-9, respectively, and are lower than the maximum allowance risk level recommended by ICRP (5.0×10-5/a). Therefore, it is at an acceptable level and will not cause obvious health hazards. There are significant difference between nitrate concentration resulting from the different hydrogeological subregions and groundwater depth. However, there are no significant differences between the land use and the nitrate concentration. The mainly sources of NO-3 pollution is the domestic sewage and chemical fertilizer in the study area. In addition, the groundwater intensely exploited is a major inducing factor for the NO-3 pollution.
-
Keywords:
- groundwater /
- over-exploited /
- nitrate /
- influencing factors /
- pollution sources
-
-
[1] ［1］ZHANG QQ, SUN JC, LIU JT, et al. Driving mechanism and sources of groundwater nitrate contamination in the rapidly urbanized region of south China［J］. Journal of Contaminant Hydrology, 2015, 182: 221-230.
[2] ［2］XUE, D M, BOTTE J, BAETS BD, et al. Present limitations and future prospects of stable isotope methods for nitrate source identification in surface-and groundwater［J］. Water Research, 2009, 43（5）: 1159-1170.
[3] ［3］PASTéN-ZAPATA E, LEDESMA-RUIZ R, HARTER T, et al. Assessment of sources and fate of nitrate in shallow groundwater of an agricultural area by using a multi-tracer approach［J］. Science of Total Environmental, 2014, 470/471（2）: 855-864.
[4] ［4］LI SL, LIU CQ, LI J, et al. Evaluation of nitrate source in surface water of southwestern China based on stable isotopes［J］. Environmental Earth Science, 2013, 68: 219-228.
[5] ［5］WHO (World Health Organization). Guidelines for Drinking-Water Quality［M］. 4th ed. Geneva: World Health Organization,2011.
[6] ［6］LANDON MK, GREEN CT, BELITE K, et al. Relations of hydrogeologic factors, groundwater reduction-oxidation conditions, and temporal and spatial distributions of nitrate, central-eastside San Joaquin Valley, California, USA［J］. Hydrogeology Journal, 2011, 19 (6):1203-1224.
[7] ［7］MARTiNEA D, MOSCHIONE E, BOCANEGRA E, et al. Distribution and origin of nitrate in groundwater in an urban and suburban aquifer in Mar del Plata, Argentina［J］. Environmental Earth Sciences, 2014, 72(6):1877-1886
[8] ［8］LOCKHART K, KING A, HARTER T. Identifying sources of groundwater nitrate contamination in a large alluvial groundwater basin with highly diversified intensive agricultural production［J］. Journal of Contaminant Hydrology. 2013, 151(6):140-154.
[9] ［9］WICK K, HEUMESSER C, SCHMID E. Groundwater nitrate contamination: factors and indicators［J］. Journal of Environmental Managment, 2012, 111(3):178-186.
[10] ［10］ZHANG X, XU Z, SUN X, et al. Nitrate in shallow groundwater in typical agricultural and forest ecosystems in China, 2004-2010［J］. Journal of Environmental Sciences, 2013, 25(5): 1007-1014.
[11] ［11］LI YS, ZHANG ZJ, FEI YH, et al. Investigation of quality and pollution characteristics of groundwater in the Hutuo River Alluvial Plain, North China Plain［J］. Environmental Earth Sciences, 2016,75(7): 1-10.
[12] ［12］中国质量监督检验检疫局. GB/T8538—2008饮用天然矿泉水检验方法［S］.北京:中国标准出版社, 2008. ［General Administration of Quality Supervision. Inspection and quarantine of the People’s Republic of China. GB/T8538—2008 Methods for examination of drinking natural mineral water［S］. Beijing: China Standards Press, 2008 (in Chinese)］
[13] ［13］符刚, 曾强, 赵亮,等. 基于GIS的天津市饮用水水质健康风险评价［J］. 环境科学, 2015, 36(12):4553-4560. ［FU G, ZENG Q, ZHAO L, et al. Health ｒisk assessment of drinking water quality in Tianjin based on GIS［J］. Environmental Science, 2015, 36(12):4553-4560 (in Chinese)］
[14] ［14］中国环境保护部. GB/3838—2002地表水环境质量标准［S］.中国环境科学出版社, 2002. ［State Environment Protection Bureau of China. GB3838—2002 Environmental quality standards for surface water［S］. Beijing: China Environmental Science Press, 2002 (in Chinese)］
[15] ［15］中国地质矿产部. GB/T14848—93地下水质量标准［S］.中国标准出版社, 1994. ［Ministry of Geology and Mineral Resources of China. GB/T14848—93 Quality standard for ground water［S］. Beijing: China Standards Press, 1994 (in Chinese)］
[16] ［16］徐建国, 李生果, 朱恒华, 等. 南四湖流域平原区浅层地下水氮污染特征［J］. 工程勘察, 2010(5): 40-44. ［XU J G, LI S G, ZHU H H, et al. The nitrogen pollution characteristics of the shallow groundwater in the Nansi lake drainage basin［J］. Geotechnical Investigation and Surveying, 2010(5): 40-44 (in Chinese)］
[17] ［17］孙世卫. 小麦—玉米轮作区地下水硝态氮含量的研究［J］. 安徽农业科学, 2007, 35: 11525-11526. ［SUN S W. Research on the nitrate nitrogen concentration of groundwater in wheat-maize rotation region［J］. Journal of Anhui Agricultural Sciences, 2007, 35: 11525-11526 (in Chinese)］
[18] ［18］GU B, GE Y, CHANG S X, et al. Nitrate in groundwater of China: sources and driving forces［J］. Global Environmental Change, 2013, 23(5): 1112-1121.
[19] ［19］LIU C Q, LI S L, LANG Y C. et al. Using delta15 N-and delta18O-values to identify nitrate sources in karst ground water, Guiyang, southwest China［J］. Environmental Science and Technology, 2006,40(22): 6928-6933.
[20] ［20］JIN Z, XUE Q, CHEN L, et al. Using dual isotopes to evaluate sources and transformations of nitrate in the West Lake watershed, eastern China［J］. Journal of Contaminant Hydrology, 2015, 177/178: 64-75.
[21] ［21］CHEN J, TANG C, SAKURA Y, et al. Nitrate pollution from agriculture in different hydrogeological zones of the regional groundwater flow system in the North China Plain［J］. Hydrogeology Journal, 2005, 13(3): 481-492.
[22] ［22］程中双. 强烈开采含水层的水化学和同位素响应及其水文地质指示［D］. 北京：中国地质科学院, 2015 ［CHENG Z S. Chemical and isotopic response to intensive groundwater exploitation and its implications: case study in thepiedmont plain, Shijiazhuang［D］. Beijing:Chinese Academy of Geological Sciences, 2015.(in Chinese)］
[23] ［23］JUAHIR H, ZAIN SM, YUSOFF MK, et al. Spatial water quality assessment of Langat River Basin (Malaysia) using environmetric techniques［J］. Environmental Monitoring and Assessment, 2011, 173(1/4): 625-641.
-
