Permeability structure of the horizontally-stratified dam foundation rock mass and its engineering significance

More Information
  • Received Date: May 05, 2021
  • Revised Date: July 09, 2021
  • Available Online: November 07, 2021
  • Published Date: January 14, 2022
  • Identifying the permeability structure of the dam foundation rock mass is important for the formulation of seepage control schemes. For the horizontally-stratified red-bed rock mass of the Yellow River Guxian Dam foundation, this paper adopted a "continuous, high-resolution" water pressure test data processing method to analyze the relationships between rock mass permeability and elevation, lithology and shear zones, clarifiy the permeability structure of the dam foundation rock mass, and propose seepage control advice. The results indicate that the Guxian Dam foundation rock mass is characterized by a structural and random permeability behavior. The structure shows that the permeability decreases with elevation. The randomness shows that the permeability randomly fluctuates due to lithology and shear zones. For the river-bed dam foundation rock mass, the bottom elevation of the weathering and unloading zone is 450 m or so, and the 1Lu bottom boundary is at the elevation of approximately 340 m. For the rock mass of the dam abutment, the 3Lu bottom boundary is located at the elevation of 560~580 m. The section of 350~360 m elevation has a certain thickness of soft rock, a poor development of shear structure, and a low permeability. It can be regarded as a confining layer and a potential target for the optimization of seepage control schemes. In view of the universal applicability, the method proposed in this paper can be used for reference in similar projects.
