van Genuchten模型参数的物理意义
Physical significance of the parameters in the van Genuchten model
-
摘要: van Genuchten模型是目前拟合水土特征曲线应用最广泛的数学模型,但该模型参数多,且物理意义复杂,特别是参数α的物理意义至今尚未有统一的认识。文章通过理论推导,结合4种样品(粗砂、中砂、细砂和粉砂)实测的水土特征曲线,对van Genuchten模型的参数α、m和n的物理意义进行了探讨,重点研究了α与进气值和拐点处负压(hi)的关系。推导出的van Genuchten模型的1/α与hi的关系和实测数据均证明了1/α不仅与hi有关,还受参数m和n的影响。粗砂和中砂的1/α与hi大致相等,细砂和粉砂的1/α则大于hi。粗砂的进气值与1/α近似相等,其它介质中1/α与进气值之间存在更复杂的关系。另外,m和n作为独立变量在拟合水土特征曲线时精度更高,但在计算非饱和渗透系数时给定m=1-1/n的约束条件是必要的。
-
关键词:
- 水土特征曲线 /
- van Genuchten模型 /
- 进气值 /
- 拐点 /
- 非饱和渗透系数
Abstract: The van Genuchten model is widely used in fitting soil-water characteristic curves. However, it has numerous parameters with the complex physical significance, and especially the parameter α has not been well understood so far. This paper discusses the physical significance of the parameters α, m and n in the van Genuchten model on the basis of the results of both theoretical derivation and the measured values of the soil-water characteristic curves of the samples (silt sand, fine sand, medium sand, coarse sand), and focuses on the relationships between parameter α and air entry values or matrix potential at the inflection point (hi). The results illustrate that the relationship between the values of 1/α and hi is related to not only hi but also the parameters m and n, and the value of 1/α is approximately equal to hi for the medium sand and coarse sand, while it is greater than hi for the fine sand and silt sand. The air entry value is equal to value of 1/α for the coarse sand, and the complex relationships occur for the other media. In addition, there is a higher degree of accuracy when the water-soil characteristic curves are fitted as m and n are independent variables. It was necessary to give a constraint condition, i.e., m=1-1/n, when the unsaturated hydraulic conductivity is calculated. -
-
[1] [1]雷志栋,杨诗秀,谢森传,等.土壤水动力学[M].北京:清华大学出版社,1988:18-24. [LEI Z D, YANG S X, XIE S C, et al. Soil water dynamics[M]. Beijing: Tsinghua University Press, 1988: 18-24 (in Chinese)]
[2] [2]Kovacs G. Seepage Hydraulics[M]. Amsterdam: Elsevier Science Publishers, 1981.
[3] [3]刘晓东,施建勇.基于土水特征曲线预测城市固体废弃物(MSW)非饱和渗透系数研究[J].岩土工程学报,2012,34(5): 855-862. [LIU X D, SHI J Y. Unsaturated conductivity of MSW based on soil-water characteristic curve[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(5): 855-862 (in Chinese)]
[4] [4]冯立, 张茂省, 孙萍萍, 等. 非饱和土脱湿与吸湿水力特性对比研究[J]. 水文地质工程地质, 2016, 43(2): 134-139. [FENG L, ZHANG M S, SUN P P, et al. A study of the hydro-mechanical properties of unsaturated loess under the drying and wetting path[J]. Hydrogeology & Engineering Geology, 2016, 43(2): 134-139 (in Chinese)]
[5] [5]Fredlund D G, Rahardjo H. Soil Mechanics for Unsaturated Soils[M]. Hoboken:Wiley, 1993.
[6] [6]王勇. 压实非饱和黏土层生活源污染质运移及其效应[D]. 徐州:中国矿业大学, 2014. [WANG Y. Life source pollutant migration and its inducing effects in unsaturated compacted clay layer[D]. Xuzhou:China University of Mining and Technology, 2014 (in Chinese)]
[7] [7]尹平保,贺炜,张建仁,等. 洞庭湖大桥锚碇基础土围堰饱和-非饱和稳定性分析[J]. 水文地质工程地质,2016,43(2): 62-68. [YIN P B, HE W, ZHANG J R, et al. Stability of soil cofferdam for anchorage foundation of the Dongting Lake bridge considering unsaturated soil characteristics[J]. Hydrogeology & Engineering Geology, 2016, 43(2): 62-68 (in Chinese)]
[8] [8]Genuchten M T V. A close-form equation for predicting the hydraulic conductivity of unsaturated soils[J]. Soil Science Society of America Journal, 1980, 44(44): 892-898.
[9] [9]Brooks R J, Corey A T. Hydraulic Properties of Porous Media[J]. Colorado State University Hydrology paper, 1964(3):22-27.
[10] [10]Gardner W R. Some steady state solutions of the unsaturated moisture flow equation with application to evaporation from a water table[J]. Soil Science, 1958, 85(4): 228-232.
[11] [11]McKee C R, Bumb A C. The importance of unsaturated flow parameters in designing a monitoring system for hazardous wastes and environmental emergencies[C]// Proceedings of Hazardous Materials Control Research Institute National Conference. Houston:1984:50-58.
[12] [12]Mckee C R, Bumb A C. Flow-Testing Coalbed Methane Production Wells in the Presence of Water and Gas[J]. Spe Formation Evaluation, 1987, 2(4): 599-608.
[13] [13]Fredlund D G, Xing A. Equations for soil-water characteristic curve[J]. Canadian Geotechnical Journal, 1994, 31: 521-532.
[14] [14]Williams J, Prebble R E, Williams W T, et al. The influence of texture, structure and clay mineralogy on the soil moisture characteristic[J]. Australian Journal of Soil Research, 1983, 21(1): 15-19.
[15] [15]Genuchten M T V, Nielsen D R. On describing and predicting the hydraulic properties of unsaturated soil[J]. Annales Geophysicae, 1985, 3(5): 615-628.
[16] [16]Benson C H, Chiang I, Chalermyanont T, et al. Estimating van Genuchten parameters α and n for clean sands from particle size distribution data[J]. Geotechnical Special Publication, 2014(233): 410-427.
[17] [17]Schaap, Marcel G, van Genuchten, Martinus Th. A modified mualem-van Genuchten formulation for improved description of the hydraulic conductivity near saturation[J]. Vadose Zone Journal, 2006, 5(1): 27-34.
[18] [18]Lenhard R J, Parker J C, Mishra S. On the correspondence between Brooks-Corey and van Genuchten models[J]. Journal of Irrigation & Drainage Engineering, 1989, 115(4): 610-611.
[19] [19]赵雅琼. 非饱和带土壤水分特征曲线的测定与预测[D]. 西安:长安大学, 2015. [ZHAO Y Q. Determination and prediction of soil water characteristic curve in unsaturated zone[D]. Xi’an: Chang’an University, 2015 (in Chinese)]
[20] [20]Sharma R S, Mohamed M H A. An experimental investigation of LNAPL migration in an unsaturated/saturated sand[J]. Engineering Geology, 2003, 70(3-4): 305-313.
[21] [21]Milly, P C D. Estimation of Brooks-Corey parameters from water retention data[J]. Water Resources Research, 1987, 23(6): 1085-1089.
[22] [22]Tinjum J M, Benson C H, Blotz L R. Soil-water characteristic curves for compacted clays”[J]. Journal of Geotechnical & Geoenvironmental Engineering, 1999,123(11):629-630.
[23] [23]Morel-Seytoux H J, Meyer P D, Nachabe M, et al. Parameter equivalence for the Brooks-Corey and van Genuchten soil characteristics: preserving the effective capillary drive[J]. Water Resources Research, 1996, 32(5): 1251-1258.
-
